Radiation Surveyor

It is used to detect X and γ-ray radiation levels in various radioactive workplaces. It has the characteristics of high sensitivity, short response time, wide measurement range and good energy response.
Add to inquiry

Product Overview

It is used to detect X and γ-ray radiation levels in various radioactive workplaces. It has the characteristics of high sensitivity, short response time, wide measurement range and good energy response.



Features

  • Medical pulse radiation and continuous radiation mobile survey;
  • Quick response to FRC algorithm, measurement when the prompt sound, that is, the measurement is ringing;
  • Automatic sense backlight, can automatically sense according to the intensity of the environment and adjust the backlight;
  • One-key record generation, one-key data preservation, easy for on-site survey records and traceability;
  • Overthreshold sound, light, vibration of multiple alarm methods, to meet the use of a variety of complex working conditions;
  • Automatic data reporting, survey data support wireless reporting to the supervision platform, convenient information statistics and analysis management (optional).



Technical Specifications

Product Model

HA3100G-P

HA3100G-P20

HA3100G-N10

HA3100G-N20

HA3100G-G

Types of detectors

Plastic scintillan

The NaI (Tl) crystal

G-M tube (energy compensation type)

Detector size

1 inch

2 inch

1 inch

2 inch

/

Measuring range

0.01μSv/h~10Sv/h

0.01μSv/h~1Sv/h

0.01μSv/h~10mSv/h

0.01μSv/h~1mSv/h

0.01μSv/h~100mSv/h

Relative inherent error

±15%

Energy range

30keV~3MeV

48keV~3MeV

60keV~3MeV

60keV~3MeV

48keV~3MeV

Communication mode

USB, Bluetooth (optional)

Power supply mode

Two AA batteries, support rechargeable batteries and dry battery
